Music theory for programmers

I can't play an instrument. I have tried more than once, and each time I got as far as being able to make roughly the right noises without ever understanding why they were the right noises.

The problem was never the practice. It was that every explanation of music theory seemed to miss out the fundamental reasons for how and why things are the way they are. Here is a staff. Here are the notes on it. This is a major scale, memorise the pattern. Why those notes? Why that pattern? Because that is the convention.

Which is a strange way to teach a system that essentially comes out of physics and arithmetic. There are twelve notes for a reason. The major scale has the shape it has for a reason. Chords that sound good sound good for a reason, and you can compute those reasons.

So I wanted to start from scratch and learn music from first principles, and I began that journey by writing code.

This article is the result. It starts with a single number changing over time, and if you follow along, you will derive the twelve notes, build scales and chords out of arrays, and write a chord progression that sounds like actual music. No instrument needed, and nothing you have to take on faith. Written notation does turn up, but not until the very end, once there is something for it to be notation of.

A sound is a number that changes over time

Sound is just air pressure wobbling. A speaker makes sound by pushing its cone in and out, and everything your computer does with audio comes down to producing a list of numbers describing where that cone should be, forty-four thousand times a second.

An audio file is that list written down. A synthesiser makes the list up as it goes, and the browser will do that part for you if you say what shape you want. The simplest shape is a sine wave, so here is one repeating 440 times a second:

const osc = ctx.createOscillator();
osc.frequency.value = 440;

osc.connect(out);
osc.start();
osc.stop(ctx.currentTime + 1);

ctx and out are mine rather than the browser's. Everything else is the Web Audio API exactly as it ships. To run that snippet anywhere else, start with:

const ctx = new AudioContext();
const out = ctx.destination;

The number 440 is the only thing there that carries any musical meaning, and even that is arbitrary. It is the frequency somebody agreed to call "A", and it is the tuning fork the rest of the system is pinned to. Change it to 300 and run it again. You get a different pitch and nothing breaks, because at this level there are no notes yet, just a number.

Frequency is pitch: higher number, higher note. That is the entire mapping, and it is the last thing about music that will be this simple.

Why that note clicked

You may have heard a little click at the end of that. That is not a bug in the browser, it is physics being unforgiving.

The oscillator was mid-wave when it stopped, so the speaker cone was somewhere out at the edge of its travel and then instantly snapped back. An instant jump in pressure is what a click is.

The fix is a second number that changes over time, this one controlling volume rather than pitch. Musicians call the shape of it an envelope:

const osc = ctx.createOscillator();
osc.frequency.value = 440;

const env = ctx.createGain();
const t = ctx.currentTime;
env.gain.setValueAtTime(0, t);
env.gain.linearRampToValueAtTime(0.3, t + 0.01);
env.gain.exponentialRampToValueAtTime(0.001, t + 1);

osc.connect(env).connect(out);
osc.start(t);
osc.stop(t + 1);

An envelope is the volume curve of a single note, from silence back to silence. The rise at the front is the attack and the fall afterwards is the decay.

Ten milliseconds to fade in, then a slow decay to nearly nothing. That is the difference between a test tone and something you would be willing to listen to twice.

Drag the attack out towards half a second and the note stops arriving and starts swelling. It is no longer something struck, it is something bowed, and the pitch has not moved by a single hertz. The envelope is doing more work here than the frequency is.

This is a simplified envelope, though. The full version is ADSR: attack, decay, sustain and release, where sustain is the level a note holds at while a key is down, and release is how it fades once you let go.

The function below is a helper that each subsequent example uses:

function note(freq, start = 0, length = 0.5, type = "sine") {
  const t = ctx.currentTime + start;
  const osc = ctx.createOscillator();
  const env = ctx.createGain();

  osc.type = type;
  osc.frequency.value = freq;

  env.gain.setValueAtTime(0, t);
  env.gain.linearRampToValueAtTime(0.3, t + 0.01);
  env.gain.exponentialRampToValueAtTime(0.001, t + length);

  osc.connect(env).connect(out);
  osc.start(t);
  osc.stop(t + length);
}

Timbre is the frequencies you did not ask for

A sine wave is a single frequency and nothing else, which is why it sounds like a hearing test and unlike any instrument. Pluck a guitar string tuned to 440Hz and you do get a wave repeating 440 times a second, but the string is also vibrating in halves, and in thirds, and in quarters, all at the same time. Those are extra frequencies at 880, 1320, 1760 and on up, all riding on top of the one you asked for.

That stack is called the harmonic series. The note you asked for is the fundamental, and the series is that frequency multiplied by 1, 2, 3, 4, 5 and on up:

Click the bars. On their own they are fairly boring. What matters is that they arrive as a package, and the recipe of how loud each one is relative to the others is what makes a violin sound like a violin and not a trumpet. Musicians call that timbre, and it is the same note either way.

The browser ships four of those recipes ready-made:

["sine", "triangle", "square", "sawtooth"].forEach((type, i) => {
  note(220, i * 0.7, 0.6, type);
});

Same 220Hz, four very different characters. A square wave contains only the odd harmonics, which is why it sounds hollow and slightly electronic. A sawtooth contains all of them and sounds harsh and buzzy. The scope above shows the shape of each one as it plays, and the shape is the harmonic recipe.

Remember the harmonic series, because it is about to explain the entire rest of this article. Every note you play drags a stack of quiet extra notes along with it, and which notes those are is not up to us. It is arithmetic, fixed by the physics of vibrating strings and columns of air, and it comes out the same on every instrument built around them.

Doubling the frequency gives you the same note

Here are five notes. Every one is double the frequency of the one before it.

[110, 220, 440, 880, 1760].forEach((freq, i) =>
  note(freq, i * 0.45, 0.4),
);

They are different pitches, and yet they sound like the same note. Not just similar, the same. Cultures with no contact with each other have landed on this independently: double the frequency and you get something so alike it deserves the same name. In Western notation these frequencies, in the above example, are all called A, and the distance between them is the octave.

The naming is not arbitrary, and the harmonic series explains why. Every harmonic of 440 is already sitting in the harmonic series of 220, because 220's series is 220, 440, 660, 880, 1100 and 440's is 440, 880, 1320, 1760. The higher note adds no frequency the lower note was not already producing. It is not a new colour, it is the same colour, brighter.

Two things fall straight out of that.

Pitch is multiplicative, not additive. Going up an octave means times two, not plus anything. The gap from 110 to 220 is 110Hz and the gap from 880 to 1760 is 880Hz, and they sound like exactly the same distance. Frequency space is logarithmic, and every interval in music is a ratio.

We only have to solve one octave. Because doubling returns you to the same note, the entire problem of "which pitches should exist" reduces to "how should we divide up the space between a frequency and twice that frequency". Solve it once and the answer tiles the whole audible range for free.

So: how do you divide an octave?

Simple ratios sound good, and here is why

The naive answer is to divide it evenly and go home. Nobody does that, because it turns out we do not experience all pairs of frequencies the same way. Some combinations sound settled and some sound like a mistake, and you can hear the difference immediately.

const ratios = [
  ["2/1   octave", 2],
  ["3/2   fifth", 3 / 2],
  ["4/3   fourth", 4 / 3],
  ["5/4   major third", 5 / 4],
  ["16/15 semitone", 16 / 15],
  ["√2    the awkward one", Math.SQRT2],
];

ratios.forEach(([label, ratio], i) => {
  note(220, i * 1.4, 1.2);
  note(220 * ratio, i * 1.4, 1.2);
  console.log(label, "->", (220 * ratio).toFixed(2) + "Hz");
});

The first four sound like chords. The 16/15 sounds like two notes arguing. The last one sounds like a car alarm. And the pattern is not subtle once you see it: the simpler the fraction, the better it sounds. 2/1 the octave, then 3/2 the fifth, then 4/3 the fourth, then 5/4 the major third, and by the time you get to 16/15 it has fallen apart entirely.

That is a suspiciously arithmetic result for something as subjective as "sounds nice", and there are two physical reasons for it.

The first is the harmonic series again. Play 220 and 330 together, which is a 3:2 ratio. The first note produces 220, 440, 660, 880, 1100, 1320. The second produces 330, 660, 990, 1320, so they share 660 and 1320 exactly. Two notes a fifth apart are not really two separate sounds, they are two heavily overlapping stacks that reinforce each other. Now try 220 and 311, which is close to √2. Nothing lines up, at any harmonic. You get two full stacks of frequencies that have nothing to do with each other.

The second reason is roughness. When two frequencies are close but not identical, they drift in and out of phase and you hear the volume pulsing. That is beating, and it is the thing that makes an out-of-tune note sound out of tune:

[220, 226, 223, 221, 220.5, 220].forEach((freq, i) => {
  note(220, i * 1.3, 1.2);
  note(freq, i * 1.3, 1.2);
});

The wobble slows down as the two frequencies converge and vanishes when they match, and the rate of it is exactly the difference between them. Six hertz apart, six pulses a second. When the fractions are complicated, the two stacks of harmonics are littered with pairs that are a few hertz apart, and every one of those pairs is beating away against the others. That is what dissonance is.

Switch between the ratios above and watch the green line, which is the two waves added together, exactly as your eardrum would add them. For 2:1 and 3:2 the combined shape settles into a repeating pattern almost immediately. For 16:15 it takes fifteen cycles to come back round. For √2 it never does, because √2 is irrational, so there is no pattern for your ear to lock onto at all.

Consonance is your ear finding a repeating pattern quickly. That is the whole mystery.

Stacking fifths, and the bug you cannot fix

Now we can actually build something. We know that simple ratios are the good ones, and after the octave itself, the cleanest ratio in physics is 3/2, the fifth.

So what happens if we try to build an entire musical alphabet using only octaves and fifths?

Do the obvious thing: keep going up by fifths, halving whenever you leave the octave. This is roughly what Pythagoras did, and it works beautifully for a while:

let freq = 220;
const notes = [220];

for (let i = 0; i < 12; i++) {
  freq = (freq * 3) / 2;
  while (freq >= 440) freq = freq / 2;
  notes.push(freq);
  console.log(`fifth ${i + 1}: ${freq.toFixed(3)}Hz`);
}

notes.sort((a, b) => a - b).forEach((f, i) => note(f, i * 0.22, 0.3));

Look at the first note and the last note. We started on 220, applied twelve fifths, and landed on 222.99. Not 220. Close enough to be audibly trying to be the same note, and far enough off to be unusable.

The error is not rounding but something structural, and it is easier to see without the octave-folding:

const twelveFifths = (3 / 2) ** 12;
const sevenOctaves = 2 ** 7;

console.log("twelve fifths:", twelveFifths.toFixed(6));
console.log("seven octaves:", sevenOctaves.toFixed(6));
console.log("ratio:", (twelveFifths / sevenOctaves).toFixed(6));
console.log(
  "in cents:",
  (1200 * Math.log2(twelveFifths / sevenOctaves)).toFixed(2),
);

note(220, 0, 1.5);
note((220 * twelveFifths) / sevenOctaves, 0, 1.5);

Twelve perfect fifths overshoot seven perfect octaves by a factor of 1.0136. That gap is called the Pythagorean comma. Cents are how pitch distances get measured, and there are 1200 of them in an octave, which is where that number in the code comes from. So 23 cents is about a quarter of the gap between two adjacent piano keys, and you can hear it in that last pair of notes as a slow ugly beating.

And it cannot be fixed, for a reason a programmer will recognise. Stacking fifths means multiplying by 3/2, so after n fifths you are at 3^n / 2^n. Stacking octaves means 2^m. For the two to ever meet you would need 3^n = 2^(n+m), which requires a power of three to equal a power of two. Three and two are both prime. It never happens, for any n, ever.

The system we want, where the octave is pure and the fifths are pure and everything closes into a neat loop, does not exist and never has. Every tuning system in history is a different choice about where to dump the error.

Equal temperament is the compromise

The modern answer is brutal and elegant. Give up on pure ratios entirely. Take the octave, divide it into twelve equal multiplicative steps, and accept that nothing except the octave will be exactly right ever again.

One step is the twelfth root of two:

const semitone = 2 ** (1 / 12);
console.log("one semitone =", semitone);

let freq = 220;
for (let i = 0; i < 13; i++) {
  note(freq, i * 0.2, 0.28);
  freq = freq * semitone;
}

console.log(
  "twelve steps later:",
  (220 * semitone ** 12).toFixed(10),
);

Twelve steps land on exactly 440, because that is how roots work, so the octave is perfect by construction and everything else is approximated.

The obvious question is why twelve. It is not tradition, and you can find the answer yourself in about fifteen lines. Divide the octave into n equal steps for every plausible n, then check how close the best available step comes to a real 3/2 fifth:

function bestFifth(n) {
  let error = Infinity;
  let step = 0;

  for (let candidate = 1; candidate < n; candidate++) {
    const off = Math.abs(2 ** (candidate / n) - 1.5);
    if (off < error) {
      error = off;
      step = candidate;
    }
  }

  return { step, error };
}

for (let n = 5; n <= 25; n++) {
  const { step, error } = bestFifth(n);
  const pct = (error / 1.5) * 100;
  console.log(
    `${n} steps: best fifth is step ${step}, off by ${pct.toFixed(3)}%`,
  );
}

// And here is what those errors actually sound like.
[5, 7, 12, 19].forEach((n, i) => {
  const { step } = bestFifth(n);
  note(220, i * 1.7, 1.5);
  note(220 * 2 ** (step / n), i * 1.7, 1.5);
});

Those last four lines play the best fifth that 5, 7, 12 and 19 divisions can manage, each against the same 220Hz. The first two wobble, the third is clean, and the fourth sits in between. You are listening to the error column.

Twelve is the first division that gets the fifth right to about a tenth of a percent, and it is more than three times better than anything below it. Twenty-four ties, but only because twenty-four steps is twelve steps with a spare note wedged between each pair, so it is not really a competitor. You have to go all the way to 29 and 41 before the fifth gets better, and nobody is building a keyboard with 41 keys per octave. It is the cheapest number of notes that buys you a convincing fifth, and once the fifth is close the fourth and the thirds come along for the ride.

Here is how close:

const pure = (220 * 3) / 2;
const tempered = 220 * 2 ** (7 / 12);

console.log("pure fifth:     ", pure.toFixed(4) + "Hz");
console.log("tempered fifth: ", tempered.toFixed(4) + "Hz");
console.log(
  "difference:     ",
  (1200 * Math.log2(tempered / pure)).toFixed(2),
  "cents",
);

note(220, 0, 1.5);
note(pure, 0, 1.5);
note(220, 2, 1.5);
note(tempered, 2, 1.5);

Two cents flat. There is a slow beat in the second pair if you listen for it, and that beat is present in every fifth played on every piano on Earth. We all decided that being slightly wrong everywhere was better than being perfect in one key and unusable in the others.

The payoff is that notes are now integers. Pick any note as number 0, and every other note is a whole number of semitones away from it. The convention is MIDI numbering, where 69 is our 440Hz A, and the conversion is one line:

const midiToFreq = (n) => 440 * 2 ** ((n - 69) / 12);

console.log("60 (middle C):", midiToFreq(60).toFixed(2));
console.log("69 (the A above it):", midiToFreq(69).toFixed(2));
console.log("81 (an octave up):", midiToFreq(81).toFixed(2));

[60, 62, 64, 65, 67, 69, 71, 72].forEach((n, i) =>
  note(midiToFreq(n), i * 0.25, 0.4),
);

That last line is a major scale, and we have not defined what a scale is yet. It is just an array of integers. From here on everything in this article is done with arrays, and I stopped needing to think about frequencies at all.

That keyboard is worth staring at for a second, because the layout is a historical accident pretending to be structure. There are twelve equally spaced notes per octave. Seven of them got letters and a big white key, five got a sharp sign and a small black key, and the seven with white keys are exactly the scale you just played. The physics underneath is completely uniform, and the keyboard is not.

Why twelve notes and not all of them

Having twelve notes does not mean using twelve notes. Play all of them in order and it is remarkably unmusical:

const midiToFreq = (n) => 440 * 2 ** ((n - 69) / 12);

for (let n = 60; n <= 72; n++) {
  note(midiToFreq(n), (n - 60) * 0.18, 0.25);
}

It sounds like a sound effect, not a tune. Every step is identical, so nothing stands out, nothing sounds like home, and there is no way to tell where you are. It is a ruler, not a melody.

Music picks a subset. Almost always seven of the twelve, chosen so that the gaps between them are uneven, which is exactly what makes it possible to tell one note from another by ear. The subset is a scale, and a scale is best written not as notes but as the steps between them:

const midiToFreq = (n) => 440 * 2 ** ((n - 69) / 12);

const major = [2, 2, 1, 2, 2, 2, 1];

function buildScale(root, pattern) {
  return pattern.reduce(
    (notes, step) => [...notes, notes.at(-1) + step],
    [root],
  );
}

const cMajor = buildScale(60, major);
console.log("C major:", cMajor);

cMajor.forEach((n, i) => note(midiToFreq(n), i * 0.25, 0.4));

The steps are 2 2 1 2 2 2 1, adding up to 12 so the pattern closes the octave exactly. That is the major scale, the single most familiar sound in Western music, and it is a seven-element array.

Change one number and it becomes a completely different mood:

const midiToFreq = (n) => 440 * 2 ** ((n - 69) / 12);
const build = (root, pattern) =>
  pattern.reduce(
    (notes, step) => [...notes, notes.at(-1) + step],
    [root],
  );

const patterns = {
  major: [2, 2, 1, 2, 2, 2, 1],
  naturalMinor: [2, 1, 2, 2, 1, 2, 2],
  majorPenta: [2, 2, 3, 2, 3],
  minorPenta: [3, 2, 2, 3, 2],
  blues: [3, 2, 1, 1, 3, 2],
};

let when = 0;
Object.entries(patterns).forEach(([name, pattern]) => {
  const scale = build(60, pattern);
  console.log(name.padEnd(13), scale.join(" "));
  scale.forEach((n, i) => note(midiToFreq(n), when + i * 0.22, 0.35));
  when += scale.length * 0.22 + 0.5;
});

Major and natural minor are the same seven-note idea with the gaps shuffled. The pentatonic scales drop two notes, which is why it is so hard to play a wrong note in them, and why every beginner guitar lesson starts there. The blues scale adds one deliberately awkward note back in.

And now the thing that made me sit up. The modes, which I had always seen presented as seven exotic Greek names to be memorised, are the same array rotated. Take the first step off the front, put it on the back, and you have the next one:

const midiToFreq = (n) => 440 * 2 ** ((n - 69) / 12);
const build = (root, pattern) =>
  pattern.reduce(
    (notes, step) => [...notes, notes.at(-1) + step],
    [root],
  );

const major = [2, 2, 1, 2, 2, 2, 1];
const names = [
  "Ionian",
  "Dorian",
  "Phrygian",
  "Lydian",
  "Mixolydian",
  "Aeolian",
  "Locrian",
];

const rotate = (arr, by) =>
  arr.map((_, i) => arr[(i + by) % arr.length]);

names.forEach((name, i) => {
  const pattern = rotate(major, i);
  console.log(name.padEnd(11), pattern.join(" "));
  build(60, pattern).forEach((n, j) =>
    note(midiToFreq(n), i * 2 + j * 0.2, 0.3),
  );
});

Seven modes, one array, seven rotations. Ionian is the major scale and Aeolian is the natural minor, which means "major" and "minor" are not two systems, they are rotation 0 and rotation 5 of the same thing. Lydian sounds dreamy and Phrygian sounds Spanish and Locrian sounds broken, and all of that comes from moving which gap sits where relative to the note you started on.

This is the point where I stopped feeling like music theory was arbitrary.

Chords are notes stacked in thirds

A chord is more than one note at the same time. Which is not much of a definition, because most combinations sound terrible. The useful question is which combinations do not.

We already know the answer from the ratios: notes whose harmonics overlap. In a scale, the notes that fit that description are the ones two scale degrees apart, a gap musicians call a third. So take a scale, pick a starting degree, and grab every other note:

const midiToFreq = (n) => 440 * 2 ** ((n - 69) / 12);
const build = (root, p) =>
  p.reduce((n, s) => [...n, n.at(-1) + s], [root]);

const cMajor = build(60, [2, 2, 1, 2, 2, 2, 1]);
const triad = [0, 2, 4].map((i) => cMajor[i]);

console.log("scale:", cMajor.join(" "));
console.log("triad:", triad.join(" "));
console.log("gaps:", triad[1] - triad[0], "and", triad[2] - triad[1]);

triad.forEach((n) => note(midiToFreq(n), 0, 2));

That is a C major chord. Three notes, at 0, 4 and 7 semitones above the note it is built on, which musicians call the root. In frequency that is 1 : 1.26 : 1.50, very nearly 4 : 5 : 6. Three simple ratios sharing harmonics all over the place. It sounds solid because the arithmetic is solid.

A third is either 4 semitones (a major third) or 3 semitones (a minor third), and stacking two of them gives you 7 semitones either way: major is 4 + 3, while minor is 3 + 4.

Now move the middle note down by one semitone:

const midiToFreq = (n) => 440 * 2 ** ((n - 69) / 12);
const chord = (shape, root, at) =>
  shape.forEach((s) => note(midiToFreq(root + s), at, 1.6));

const shapes = {
  major: [0, 4, 7],
  minor: [0, 3, 7],
  diminished: [0, 3, 6],
  augmented: [0, 4, 8],
};

Object.entries(shapes).forEach(([name, shape], i) => {
  console.log(name.padEnd(11), shape.join(" "));
  chord(shape, 60, i * 2);
});

Major to minor is one note moving by one semitone. That is the entire difference between the two emotional poles of Western music, and it is [0,4,7] versus [0,3,7]. Diminished squashes both gaps and sounds unresolved and anxious. Augmented stretches both and sounds like something is about to go wrong in a film.

I found this genuinely annoying to discover, in a good way. I had absorbed the idea that major and minor were deep categories. They are a single array element differing by one.

Add a fourth note, another third up, and you get seventh chords, which are where music starts sounding less like a hymn and more like something you would hear on purpose:

const midiToFreq = (n) => 440 * 2 ** ((n - 69) / 12);

const shapes = {
  "major 7th": [0, 4, 7, 11],
  "minor 7th": [0, 3, 7, 10],
  "dominant 7th": [0, 4, 7, 10],
};

Object.entries(shapes).forEach(([name, shape], i) => {
  console.log(name.padEnd(13), shape.join(" "));
  shape.forEach((s) => note(midiToFreq(60 + s), i * 2.2, 1.8));
});

Major 7th is the jazz-cafe chord. Minor 7th is smooth and slightly melancholy. The dominant 7th is the interesting one. Dominant is just the traditional name for the fifth degree of a scale, and this chord is about to do a lot of work.

A key gives you seven chords for free

Here is the part that finally made chord charts stop looking like hieroglyphics.

There is nothing special about starting on the first degree. Do it from each of the seven in turn, wrapping around the octave, and you get seven chords, all built only from the seven notes of the scale:

const midiToFreq = (n) => 440 * 2 ** ((n - 69) / 12);
const build = (root, p) =>
  p.reduce((n, s) => [...n, n.at(-1) + s], [root]);

const scale = build(60, [2, 2, 1, 2, 2, 2, 1]).slice(0, 7);
const names = ["C", "D", "E", "F", "G", "A", "B"];

const chordOn = (degree) =>
  [0, 2, 4].map((step) => {
    const i = degree + step;
    return scale[i % 7] + Math.floor(i / 7) * 12;
  });

names.forEach((name, degree) => {
  const notes = chordOn(degree);
  const shape = notes.map((n) => n - notes[0]);
  const quality =
    shape[1] - shape[0] === 4
      ? "major"
      : shape[2] - shape[0] === 6
        ? "diminished"
        : "minor";
  console.log(`${name} ${quality.padEnd(11)} ${notes.join(" ")}`);
  notes.forEach((n) => note(midiToFreq(n), degree * 1.5, 1.3));
});

Nobody chose those qualities. Three of them come out major, three come out minor, and the last one comes out diminished, and that pattern is forced by the uneven gaps in the scale. Start the every-other-note process on a degree whose neighbours are spaced 4 then 3, you get a major chord. Spaced 3 then 4, you get a minor one.

Musicians write those seven as Roman numerals: capital for major, lowercase for minor, and a small circle for the diminished one.

I ii iii IV V vi vii°

That notation is doing something useful, and it took me an embarrassingly long time to notice what. It describes chords by their position in the scale, not by their name. A V chord is "the chord built on the fifth degree", whatever key you are in, which is relative addressing. A chord chart written in Roman numerals is key-independent source, and transposing is adding a constant:

const midiToFreq = (n) => 440 * 2 ** ((n - 69) / 12);
const build = (root, p) =>
  p.reduce((n, s) => [...n, n.at(-1) + s], [root]);

function chordsInKey(root) {
  const scale = build(root, [2, 2, 1, 2, 2, 2, 1]).slice(0, 7);
  return (degree) =>
    [0, 2, 4].map((step) => {
      const i = degree - 1 + step;
      return scale[i % 7] + Math.floor(i / 7) * 12;
    });
}

// The same four numerals, played in two different keys.
const progression = [1, 5, 6, 4];

[60, 65].forEach((key, k) => {
  const chord = chordsInKey(key);
  progression.forEach((numeral, i) => {
    chord(numeral).forEach((n) =>
      note(midiToFreq(n), k * 7 + i * 1.6, 1.5),
    );
  });
});

Same shape, two different starting notes, and your ear recognises it as the same music, which is the whole reason the notation exists.

Tension and resolution

One chord is just a sound. Music is what happens when you put them in an order, and the order matters. Some sequences feel like they have arrived and some feel like a question.

The strongest pull in the entire system is from V back to I, and there are two concrete reasons for it.

const midiToFreq = (n) => 440 * 2 ** ((n - 69) / 12);
const play = (notes, at, len = 1.6) =>
  notes.forEach((n) => note(midiToFreq(n), at, len));

const C = [60, 64, 67]; // I
const G7 = [55, 59, 62, 65]; // V7

play(G7, 0, 1.8);
play(C, 2, 2.2);

console.log("B is", 59, "and C is", 60, "- one semitone apart");
console.log("F is", 65, "and E is", 64, "- one semitone apart");

First, the note B sits in the V chord and is one semitone below the root of I. A note that close to a destination sounds like it is leaning on the door. Musicians call it the leading tone, and it is doing the same job as a cliffhanger.

Second, the dominant 7th chord contains both B and F, which are six semitones apart. Six semitones is the tritone, exactly half an octave: 2 ** (6/12) is the square root of two, the exact irrational ratio we heard earlier. The single most unstable interval available, sitting inside the chord, and both of its notes resolve by one semitone in opposite directions when you move to I. The tension is not a metaphor, it is a specific irrational ratio being replaced by simple ones.

The whole language of tension and release is built on that mechanism. Here it is with a few of the progressions you have heard ten thousand times:

const midiToFreq = (n) => 440 * 2 ** ((n - 69) / 12);
const build = (root, p) =>
  p.reduce((n, s) => [...n, n.at(-1) + s], [root]);

const scale = build(60, [2, 2, 1, 2, 2, 2, 1]).slice(0, 7);
const chord = (degree) =>
  [0, 2, 4].map((step) => {
    const i = degree - 1 + step;
    return scale[i % 7] + Math.floor(i / 7) * 12;
  });

const progressions = {
  "I  V  vi IV": [1, 5, 6, 4],
  "ii V  I": [2, 5, 1],
  "I  vi IV V": [1, 6, 4, 5],
  "vi IV I  V": [6, 4, 1, 5],
};

let when = 0;
Object.entries(progressions).forEach(([name, degrees]) => {
  console.log(
    name,
    "->",
    degrees.map((d) => chord(d).join("/")).join("  "),
  );
  degrees.forEach((d, i) => {
    chord(d).forEach((n) => note(midiToFreq(n), when + i * 1.1, 1));
  });
  when += degrees.length * 1.1 + 0.9;
});

I V vi IV is the four chords that a genuinely alarming share of pop music is built from. ii V I is the backbone of jazz. vi IV I V is the same four chords as the first one, rotated to start somewhere sadder.

Edit the arrays. Almost any sequence of numbers from 1 to 7 will hang together, because every chord is built from the same seven notes. A key buys you a constrained space where wrong answers are hard to reach. Ending on 1 sounds finished, ending on 5 sounds like there is another line coming, and ending on 7 sounds like something has gone wrong.

Notation is a serialisation format

None of what came before needed a staff. Everything above is arrays of integers and a function that turns them into frequencies.

But notation exists, it is the format the entire literature of Western music is stored in, and once you already know what it is encoding it turns out to be a fairly sensible design with some very old constraints. It is a serialisation format, written before printing was cheap, optimised for a human reading it in real time while their hands are busy, and never revised because the install base was too large.

Here is the C major scale, the same seven integers as before:

The vertical axis is pitch, but not linearly. Each line and each space is one step up the scale, so consecutive positions are sometimes two semitones apart and sometimes one. The axis is diatonic rather than chromatic: it steps through the scale rather than through all twelve notes, which means it is showing you scale degrees dressed up as pitches. That is why the major scale looks like a boring straight run up the page and sounds like the most natural sequence in the world. The format is optimised for the case it expects.

The clef declares the origin. A staff is five lines with nothing pinning it to any frequency, so the symbol at the front tells you where you are. The treble clef is a stylised G, and the curl of it wraps around the line that means G. The bass clef is a stylised F with two dots straddling the F line. It is a coordinate system with the origin marked in the margin:

Same shape on the page, different origin, so it plays back an octave down. Two clefs cover the ranges people actually sing and play, which is why there are two and not twenty.

Accidentals patch the lossy encoding. Seven vertical positions per octave, twelve notes to represent. The sharp, flat and natural signs are the escape hatch, and every one of them is an instruction to shift the note the position would otherwise mean:

The key signature is DRY. If a piece is in D major, its scale contains F sharp and C sharp, and every single F and C in the piece would need a sharp sign next to it. So instead you declare it once, at the front of every line, and it applies until something says otherwise. It is a constant hoisted to the top of the file:

Note that the two sharps are still being played, they are just not written on each note. This is also why sheet music tells you the key before you have played anything, and why musicians talk about a piece being "in" a key. The key is in the header, not the body.

Durations are powers of two. A whole note, a half note, a quarter, an eighth, a sixteenth. Each one is half the last, and the notation encodes the exponent visually: an empty notehead, then a stem, then a flag per halving. It is a unary encoding of a binary exponent, which is a very medieval way to store a number and impossible to misread at a glance:

Powers of two get you a long way but not everywhere, so there is one more operator: a dot after a notehead multiplies its length by 1.5. Two dots multiply by 1.75. It is a binary fraction, written as punctuation.

None of these durations are times, though. They are beats, and beats become seconds only when you fix a tempo:

const midiToFreq = (n) => 440 * 2 ** ((n - 69) / 12);

const bpm = 120;
const beat = 60 / bpm;

// [midi note, length in beats]
const melody = [
  [60, 1],
  [62, 1],
  [64, 2],
  [65, 0.5],
  [67, 0.5],
  [69, 3],
];

let when = 0;
melody.forEach(([n, beats]) => {
  note(midiToFreq(n), when, beats * beat * 0.95);
  when += beats * beat;
});

console.log("total:", when.toFixed(2), "seconds at", bpm, "bpm");

Change bpm to 200 and the same array is the same tune, faster. That split is the reason a score is portable at all. It stores relative durations, and the performer supplies the clock.

The time signature groups the beats. 4/4 means four quarter-note beats per bar, 3/4 means three, and the vertical bar lines are there so your eye can find its place on a page. It is mostly a readability feature, but it also carries a real musical claim, which is that the first beat of each group is the strong one. Play the same six notes grouped in threes and grouped in twos and they become different pieces of music.

That is genuinely all of it. Pitch on a diatonic axis with an origin and an escape hatch, duration as negative powers of two, and a couple of header fields. Everything else on a page of sheet music is performance instructions layered on top: how loud, how smoothly, which finger.

Putting it together

Here is everything above in one place. A key, its diatonic chords, a progression, those chords broken into an arpeggio one note at a time, and a melody that sticks to the scale. About forty lines, no library, and it is the first thing I made with code that I would describe as music rather than as a demonstration:

const midiToFreq = (n) => 440 * 2 ** ((n - 69) / 12);
const build = (root, p) =>
  p.reduce((n, s) => [...n, n.at(-1) + s], [root]);

const key = 57; // A
const scale = build(key, [2, 1, 2, 2, 1, 2, 2]).slice(0, 7); // natural minor
const bpm = 104;
const beat = 60 / bpm;

const chord = (degree) =>
  [0, 2, 4].map((step) => {
    const i = degree - 1 + step;
    return scale[i % 7] + Math.floor(i / 7) * 12;
  });

const progression = [1, 6, 3, 7];
const melody = [0, 2, 4, 2, 3, 2, 1, 0, 4, 3, 2, 1, 0, 2, 1, 0];

progression.forEach((degree, bar) => {
  const at = bar * 4 * beat;
  const notes = chord(degree);

  // Bass note on the downbeat.
  note(midiToFreq(notes[0] - 12), at, beat * 3.6, "triangle");

  // Arpeggio: up, down, up, across the bar.
  [0, 1, 2, 1, 0, 1, 2, 1].forEach((which, i) => {
    note(midiToFreq(notes[which]), at + i * beat * 0.5, beat * 0.45);
  });

  // Melody, four notes per bar, always from the scale.
  melody.slice(bar * 4, bar * 4 + 4).forEach((step, i) => {
    note(
      midiToFreq(scale[step % 7] + 12),
      at + i * beat,
      beat * 0.9,
      "triangle",
    );
  });
});

Every number in there means something we derived. 57 is A because of the twelfth root of two and a tuning fork. [2,1,2,2,1,2,2] is the minor scale because it is the major scale rotated five places. [0,2,4] is a chord because harmonics overlap when notes are two scale degrees apart. [1,6,3,7] sounds like it goes somewhere because of where the tension sits.

Change the key to 60 and it moves. Change the scale pattern to [2,2,1,2,2,2,1] and the same tune turns cheerful. Change the melody array to anything at all and it will still fit, because it is indexing into the scale rather than choosing frequencies, and that constraint is doing all the work that theory is for.

What I still do not understand

Quite a lot. This article covers pitch and almost nothing else, and pitch may be the easy half.

Rhythm I have barely touched, and everything I have read suggests it is deeper than it looks. Voice leading, which is the business of moving between chords by the smallest possible distance rather than jumping around, is where written music starts sounding good rather than merely correct, and I can state the rule without hearing why it works. Why a melody wants to land where it lands is still mostly opaque to me. And the whole thing above is one tradition's answer. Plenty of music divides the octave differently, or does not treat the octave as the unit at all, and none of it is wrong.

But I no longer feel like I am being asked to memorise trivia. The twelve notes are a rounding error negotiated between the primes two and three. Scales are subsets chosen so the gaps are uneven enough to navigate by. Chords are the notes whose harmonics already agree. Keys are relative addressing. Notation is a serialisation format with a header. Every one of those is a normal engineering decision, made a long time ago, under constraints, and the reasons survive if you go looking.

If you want to go further, the two things that made me start writing this were Music Theory for Nerds by Eevee, which is a great read, and LightNote, which is the most beautiful thing on the internet about this subject. For the API side, MDN's Web Audio documentation is unusually good.

Every example on this page is plain JavaScript with no dependencies, so all of it runs anywhere with a browser engine. If you want to keep pulling on the thread, RunJS is a JavaScript playground where you can very easily experiment with code like this without needing to set anything up. It has the Web Audio API available out of the box. Paste any of the snippets above into it, add const ctx = new AudioContext() and const out = ctx.destination at the top, and carry on from there.
